- IXOLAR™ High Efficiency SolarBIT™ & SolarMD™
-
Description
IXOLAR™ is IXYS’ product line of SolarBIT™ & SolarMD™ made of monocrystalline, high efficiency solar cells.
The IXOLAR™ is an ideal for charging various battery powered and handheld consumer products such as mobile phones, cameras, RF-ID Tag, PDAs, MP3-Players and toys.
They are also suitable for industrial applications such as wireless sensors, portable instrumentation and for charging emergency backup batteries.
With a cell efficiency of typically 25% measured at a wafer level, SolarBITs give the ability to extend run time even in “low light” conditions and increase battery life and run time in a small footprint, which can be easily accommodated in the design of portable products.
The design allows connecting SolarBITs flexibly in series and/or parallel to perfectly meet the application’s power requirements.
IXOLAR™ products have a very good response over a wide wavelength range and therefore can be used in both indoor and outdoor applications.
Gen2 Standard Products (1.8mm thickness)
| NO | Part Number | Gen | Voc | Isc | Pmax | Vmax | Imax | Jsc | F. F. | Cell eff. |
ΔVOC | ΔISC | Dimension | Weight | Unit Subcell |
Subcells | Recommended charger IC |
Status | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| (V) | (mA) | (mW) | (V) | (mA) | (mA /cm2) |
(%) | (%) | (mV/K) | (uA/K) | (mm) | (grams) | (mm) | Para | Series | |||||
| 1 | KXOB25-12X1F | 2 | 0.69 | 46.7 | 24.5 | 0.56 | 43.9 | 41.4 | >70 | 25.0 | -1.7 | 20 | 22 x 7 x 1.8 | 0.5 | 20.0 x 5.65 | 1 | 1 | BQ25504,05,70 | Active |
| 2 | KXOB25-04X3F | 2 | 2.07 | 14.0 | 22.0 | 1.67 | 13.2 | 41.4 | >70 | 25.0 | -5.2 | 10 | 22 x 7 x 1.8 | 0.5 | 6.0 x 5.65 | 1 | 3 | BQ25504,05,70 | Active |
| 3 | KXOB25-01X8F | 2 | 5.53 | 5.9 | 24.5 | 4.46 | 5.5 | 41.4 | >70 | 25.0 | -13.9 | 3 | 22 x 7 x 1.8 | 0.5 | 5.0 x 2.83 | 1 | 8 | BQ25504,05,70 | Active |
| 4 | SM111K04L | 2 | 2.76 | 46.7 | 98.0 | 2.23 | 43.9 | 41.4 | >70 | 25.0 | -7.0 | 20 | 43 x 14 x 1.8 | 2.5 | 20.0 x 5.65 | 1 | 4 | BQ25504,05,70 | Active |
| 5 | SM111K06L | 2 | 4.15 | 46.7 | 146.9 | 3.35 | 43.9 | 41.4 | >70 | 25.0 | -10.4 | 20 | 41 x 21 x 1.8 | 3.5 | 20.0 x 5.65 | 1 | 6 | BQ25504,05,70 | Active |
| 6 | SM111K08L | 2 | 5.53 | 46.7 | 195.9 | 4.46 | 43.9 | 41.4 | >70 | 25.0 | -13.9 | 20 | 87 x 14 x 1.8 | 5.0 | 20.0 x 5.65 | 1 | 8 | BQ25504,05,70 | Active |
| 7 | SM111K09L | 2 | 6.22 | 46.7 | 220.4 | 5.02 | 43.9 | 41.4 | >70 | 25.0 | -15.7 | 20 | 62 x 21 x 1.8 | 5.5 | 20.0 x 5.65 | 1 | 9 | SPV1050 | Active |
| 8 | SM111K10L | 2 | 6.91 | 46.7 | 244.9 | 5.58 | 43.9 | 41.4 | >70 | 25.0 | -17.4 | 20 | 42 x 35 x 1.8 | 4.5 | 20.0 x 5.65 | 1 | 10 | SPV1050 | Active |
| 9 | SM340K10L | 2 | 6.91 | 14.0 | 73.5 | 5.58 | 13.2 | 41.4 | >70 | 25.0 | -17.4 | 10 | 34 x 16 x 1.8 | 2.0 | 6.0 x 5.65 | 1 | 10 | SPV1050 | Active |
| 10 | SM470K12L | 2 | 8.29 | 19.5 | 122.5 | 6.70 | 18.3 | 41.4 | >70 | 25.0 | -20.9 | 10 | 22 x 35 x 1.8 | 2.5 | 10.0 x 4.71 | 1 | 12 | SPV1050 | Active |
| 11 | SM560K10L | 2 | 6.91 | 23.4 | 122.5 | 5.58 | 21.9 | 41.4 | >70 | 25.0 | -17.4 | 10 | 22 x 35 x 1.8 | 2.5 | 10.0 x 5.65 | 1 | 10 | SPV1050 | Active |
| 12 | SM710K12L | 2 | 8.29 | 29.2 | 183.7 | 6.70 | 27.4 | 41.4 | >70 | 25.0 | -20.9 | 10 | 32.5 x 33 x 1.8 | 4.5 | 15.0 x 4.71 | 1 | 12 | SPV1050 | Active |
| 13 | SM850K12L | 2 | 8.29 | 35.1 | 220.5 | 6.70 | 32.9 | 41.4 | >70 | 25.0 | -20.9 | 20 | 38.5 x 33 x 1.8 | 4.5 | 18.0 x 4.71 | 1 | 12 | SPV1050 | Active |
| 14 | SM940K09L | 2 | 6.22 | 39.0 | 183.7 | 5.02 | 36.6 | 41.4 | >70 | 25.0 | -15.7 | 20 | 44.5 x 21.5 x 1.8 | 4.5 | 20.0 x 4.71 | 1 | 9 | SPV1050 | Active |
| 15 | SM940K12L | 2 | 8.29 | 39.0 | 245.0 | 6.70 | 36.6 | 41.4 | >70 | 25.0 | -20.9 | 20 | 42 x 35 x 1.8 | 4.5 | 20.0 x 4.71 | 1 | 12 | SPV1050 | Active |
| 16 | SM301K09L | 2 | 6.22 | 126.2 | 595.1 | 5.02 | 118.5 | 41.4 | >70 | 25.0 | -15.7 | 60 | 58 x 58 x 1.8 | 12.0 | 18.0 x 5.65 | 3 | 9 | SPV1050 | Active |
| 17 | SM451K08L | 2 | 5.53 | 186.9 | 783.7 | 4.46 | 175.6 | 41.4 | >70 | 25.0 | -13.9 | 80 | 89 x 55 x 1.8 | 18.0 | 20.0 x 11.30 | 2 | 8 | BQ25504,05,70 | Active |
| 18 | SM451K10L | 2 | 6.91 | 186.9 | 979.6 | 5.58 | 175.6 | 41.4 | >70 | 25.0 | -17.4 | 80 | 89 x 67 x 1.8 | 20.0 | 20.0 x 11.30 | 2 | 10 | BQ24650 & LT3652 | Active |
| 19 | SM451K12L | 2 | 8.29 | 186.9 | 1175.6 | 6.70 | 175.6 | 41.4 | >70 | 25.0 | -20.9 | 80 | 90 x 79 x 1.8 | 22.0 | 20.0 x 11.30 | 2 | 12 | BQ24650 & LT3652 | Obsolete |
| 20 | SM232K10L | 2 | 6.91 | 967.7 | 5071.5 | 5.58 | 908.8 | 41.4 | >70 | 25.0 | -17.4 | 440 | 215 x 132 x 2.4 | 110.0 | 117.0 x 20.00 | 5 | 10 | BQ24650 & LT3652 | Obsolete |
